Stauff SE-070-H-10-B/4 Replaces the Stauff SE070H10B
Stauff SE-070-H-10-B/4 Pressure Filter | Replaces the Stauff SE070H10B
SE-070-H-10-B/4
Stauff
Stauff SE070H10B
Stauff
Stauff SE070H10B
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 175 Sealing: NBR, β ratio >200
Regular price
$ 3,379.00
Unit price
per
16 pcs
Germany
8421.99.90
1.54 kg
0.0008 m³
16 pcs
United Kingdom
8421.99.90
0.7 kg
0.0008 m³
16 pcs
Italy
8421.99.90
0.75 kg
0.002 m³
16 pcs
United States
8421.29.80.90
0.76 kg
0.0015 m³
16 pcs
France
8421.99.90
1.04 kg
0.0032 m³
16 pcs
Mexico
8421.23.00
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 175 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 69.0 mm |
| Inner Diameter | 34.1 mm |
| Length | 173.0 mm |
| Δ Collapse Pressure | 210 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff SE-070-H-10-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
