Stauff SE-045-H-05-B/4 Replaces the Stauff SE045H05B
Stauff SE-045-H-05-B/4 Pressure Filter | Replaces the Stauff SE045H05B
SE-045-H-05-B/4
Stauff
Stauff SE045H05B
Stauff
Stauff SE045H05B
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 116 Sealing: NBR, β ratio >200
Regular price
$ 2,600.00
Unit price
per
1344 pcs
Germany
8421.99.90
0.28 kg
0.0011 m³
1344 pcs
United States
8421.29.80.90
1.32 kg
0.0005 m³
1344 pcs
United Kingdom
8421.99.90
0.61 kg
0.0006 m³
1344 pcs
Italy
8421.99.90
0.5 kg
0.0009 m³
1344 pcs
France
8421.99.90
0.58 kg
0.0008 m³
1344 pcs
Germany
8421.23.00
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 116 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 5µ @ β200 |
| Efficiency 2 | 7µ @ β1000 |
| Outer Diameter | 69.0 mm |
| Inner Diameter | 34.1 mm |
| Length | 115.0 mm |
| Δ Collapse Pressure | 210 bar |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Stauff Product
Genuine Stauff SE-045-H-05-B/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
