Stauff RD-055-L-20-B Replaces the Stauff RD-055-K-20-B

Stauff RD-055-K-20-B
Stauff RD-055-K-20-B
Representative product image Product image feedback

Stauff RD-055-L-20-B Return Filter | Replaces the Stauff RD-055-K-20-B

Brand: Stauff
Description

Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Filter Paper Outer Diameter (mm): 83 Inner Diameter (mm): 40,2 Length (mm): 197 Sealing: NBR, β ratio >2

Price Match
$ 1,954.00
480 pcs
Germany
8421.99.90
0.4 kg
0.0017 m³
480 pcs
France
8421.99.90
0.5 kg
0.0014 m³
480 pcs
Italy
8421.99.90
0.66 kg
0.0034 m³
480 pcs
Italy
8421.29.80.90
Shipping Terms

Description

Replacement Filter Element for Return-Line Filters Micron Rating: 20 µm Material: Filter Paper Outer Diameter (mm): 83 Inner Diameter (mm): 40,2 Length (mm): 197 Sealing: NBR, β ratio >2

Specification

StyleReturn Filter
MediaCellulose
Efficiency 125µ @ β2
Outer Diameter 83.0 mm
Inner Diameter 40.3 mm
Length 197.0 mm
Δ Collapse Pressure 8 bar
Seal MaterialGuarnital
Temperature Range -30 - +100°C
Stauff Brand Logo

Stauff Product

Genuine Stauff RD-055-L-20-B

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
25µ @ β2
Efficiency 2
Style Return Filter
Outer Diameter 83.0 mm
Inner Diameter 40.3 mm
Length 197.0 mm
Media Type Cellulose
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 8 BAR
Seal Guarnital
Temperature Range -30 - +100°C
