MicroFit MFHR51360 Replaces the Ikron HHC01273

HHC01273
HHC01273
Representative product image Product image feedback

MicroFit® UltraGen III MFHR51360 Return Filter | Replaces the Ikron HHC01273

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHR51360 is the MICROFIT® approved replacement to the Ikron HHC01273. Engineered and manufactured in Great Britain the MFHR51360

Price Match
$ 1,675.00
0.76 kg
0.0022 m³
United Kingdom
8421.99.90
0.76 kg
0.0022 m³
Italy
8421.99.90
0.72 kg
0.0025 m³
France
8421.99.90
Shipping Terms

Description

The MICROFIT® UltraGen III MFHR51360 is the MICROFIT® approved replacement to the Ikron HHC01273. Engineered and manufactured in Great Britain the MFHR51360

Specification

StyleReturn Filter
MediaGlass Fiber
Efficiency 13µ @ β200
Efficiency 25µ @ β1000
Outer Diameter 99.0 mm
Inner Diameter 40.5 mm
Length 210.0 mm
Bypass Pressure 1.7 BAR bar
Δ Collapse Pressure 10 bar
Seal MaterialNitrile
Temperature Range -30 - +100°C
Default Brand Logo

Same Fit-Form & Function

As the Genuine Ikron HHC01273

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
3µ @ β200
Efficiency 2 5µ @ β1000
Style Return Filter
Outer Diameter 99.0 mm
Inner Diameter 40.5 mm
Length 210.0 mm
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

1.7 BAR
Collapse Pressure 10 BAR
Seal Nitrile
Temperature Range -30 - +100°C
